PSR 5862G Dual Ball Bearing Turbocharger HP Rating 770
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
PSR 5862G Dual Ball Bearing Turbocharger HP Rating 770
DESCRIPTION:
- Dual ceramic ball bearing system provides optimal turbo response &
better durability by reducing the shaft-motion - 9 Blade G-Aero billet compressor wheel with extended tapered tip technology
- 9 Blade G-Aero Inconel 713c turbine wheel
- Anti-Surge ported-shroud compressor inlet, cover integrated with the speed sensor port
- Compressor Wheel: 58*71mm
- Turbine Wheel: 68*62mm
- Compressor Inlet: 4” Hose
- Compressor Outlet: 2” Hose
- Turbine Inlet: T3/T4/V-Band
- Turbine Outlet: 3” V-Band
- Water Ports: 2-M14 x 1.5
- Oil Feed: 7/16-24 UNF with a -4AN Restrictor Pre-installed
- Oil Drain: Std T3
- Comes with Inlet flange and clamp (DVB) and Outlet flange and clamp
| Product Name | PSR 5862G Dual Ball Bearing Turbocharger HP Rating 770 |
|---|---|
| Brands | Pulsar |
Delivery & Freight
We are an Australian-based company that ships items nationally and internationally, usually within 48 hours of receiving your order. High-value items shipped internationally are sent via DHL Express, while lower-value items are sent via Australia Post Express unless otherwise instructed.
You can calculate shipping rates inside the shopping cart. After adding all the products you would like, navigate to the cart and click the ESTIMATE SHIPPING & TAX link. .
If you only see the Click and Collect shipping option, it means that your address was not validated correctly.
If you have issues calculating freight, please get in touch. We are happy to help.
Disclaimer:
Product images are for description purposes only. Actual product may vary.
Shipping calculations available at checkout.
If you are unsure, get in touch by emailing [email protected], messaging us on Facebook, or phoning us at +61 7 5645 1333 (8am to 2pm AET).
How do I choose the right turbo size?
Turbo selection depends on engine size, boost target, rpm range and desired response. A smaller turbo spools faster; a larger turbo supports more top-end power.
Why is wastegate placement important?
Poor placement or sizing can cause boost creep or unstable boost control.
What is the recommended oil feed and drain setup for the PSR 5862G turbocharger?
The PSR 5862G turbocharger features a 7/16-24 UNF oil feed with a -4AN restrictor pre-installed. For the oil drain, it uses a standard T3 configuration. Ensure proper oil supply and drainage to maintain optimal performance and prevent turbo failure.
What are the dimensions of the compressor and turbine wheels on the PSR 5862G?
The PSR 5862G turbocharger has a compressor wheel size of 58mm x 71mm and a turbine wheel size of 68mm x 62mm. These dimensions contribute to its performance capabilities and efficiency.
What type of bearing system does the PSR 5862G use and how does it benefit performance?
The PSR 5862G utilises a dual ceramic ball bearing system. This design enhances turbo response and durability by reducing shaft motion, allowing for quicker spool times and improved reliability under high-performance conditions.
What are the inlet and outlet sizes for the compressor and turbine on the PSR 5862G?
The compressor inlet of the PSR 5862G is designed for a 4-inch hose, while the compressor outlet is compatible with a 2-inch hose. The turbine inlet is a T3/T4/V-Band configuration, and the turbine outlet is a 3-inch V-Band.
Does the PSR 5862G turbocharger have any specific installation requirements?
When installing the PSR 5862G, ensure that the anti-surge ported-shroud compressor inlet is positioned correctly for optimal airflow. Additionally, confirm that the water ports (2-M14 x 1.5) are connected properly to manage cooling effectively.
-
-
-
-
