Carrillo Conrods for 6 cyl Nissan TB48 Super-A 3/8 Bolt (NI-TB48<SA-66437H )

Name: Carrillo Conrods for 6 cyl Nissan TB48 Super-A 3/8 Bolt (NI-TB48<SA-66437H )
Brand: Carrillo
SKU: SCR5443
Price: 2985 AUD
Availability: InStock

Price is for a set of Conrods

This conrod is special order, please allow up to 2 weeks for delivery if not in stock at CP Carrillo we will let you know the ETA.

Be the first to review this product

AUD$2,713.64

SKU

SCR5443

Quantity:

+ -

Add to Compare

Add to Wish List Share

Copy Link

For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.

Details

More Information

DELIVERY & FREIGHT

DISCLAIMER

Faq

Make	Nissan / Infiniti / Datsun
Model Engine Code	T48
New Part Number	SCR5443
Old Part Number	NI-TB48
Centre to Centre (in)	6.437
Centre to Centre (mm)	163.4998
Style	PRO-SA
Bolt Size	3/8
Bolt Type	WMC
Pin Width (in)	1.02
Pin Width (mm)	25.908
Big End Width (in)	1.29
Bigh End Width (mm)	32.766
Big End Bore (in)	2.3622
Big End Bore (mm)	59.99988
Pin Bore	23mm
Total/Rotate/Receip (grams)	785 / 555 / 230
FN	H
Cylinders	6

Manufactured from USA made oversized proprietary steel forgings to enable proper grain flow and guarantee removal of any surface inclusions, CP-Carrillo ensures strength and durability of each Carrillo rod. Consistent and reliable from the first point of precision manufacturing all the way to extreme uses in racing world, exclusive Carrillo H beam and Pro (S)A designs offer the highest strength-to-weight ratio; Custom designed fasteners; 100 traceability; multi-step final inspection; CP-Carrillo moly based fastener lubrication included.

More Information
Product Name	Carrillo Conrods for 6 cyl Nissan TB48 Super-A 3/8 Bolt (NI-TB48
Brands	Carrillo
Engine	TB48
Make	Nissan

Delivery & Freight

We are an Australian-based company that ships items nationally and internationally, usually within 48 hours of receiving your order. High-value items shipped internationally are sent via DHL Express, while lower-value items are sent via Australia Post Express unless otherwise instructed.

You can calculate shipping rates inside the shopping cart. After adding all the products you would like, navigate to the cart and click the ESTIMATE SHIPPING & TAX link. .

If you only see the Click and Collect shipping option, it means that your address was not validated correctly.

If you have issues calculating freight, please get in touch. We are happy to help.

If you are outside of Australia, you are responsible for any duty or taxes charged by your government."

Disclaimer:

Product images are for description purposes only. Actual product may vary.

Shipping calculations available at checkout.

If you are unsure, get in touch by emailing [email protected], messaging us on Facebook, or phoning us at +61 7 5645 1333 (8am to 2pm AET).

What bolts do these conrods use and how should I tighten them?

These rods use ARP conrod bolts, usually ARP2000 as standard with L19 or CA625+ available on some models. ARP2000 bolts are generally torqued to around 55 ft-lb for 3/8 inch and around 75 ft-lb for 7/16 inch when using ARP Ultra-Torque lube. L19 bolts must be tightened by stretch, not torque. Always refer to the latest ARP instructions for exact specifications.

Do these conrods have a horsepower rating or warranty?

No. Like other performance rods, they do not carry a horsepower or performance warranty. Spool warrants workmanship before installation, but once fitted, power handling depends entirely on machining, clearances, tuning, fuel, boost level and rpm.

Do the big end and small end need machining?

They often do. Crank journals and pin bores vary between engines, so your builder should measure the big end oil clearance and small end pin clearance and hone as required before assembly.

What are the specific machining requirements for the SCR5443 conrods?

The SCR5443 conrods may require honing of the big-end and small-end to ensure proper fitment due to manufacturing tolerances. Always check the journal and pin sizes before installation.

What is the recommended application for the Carrillo SCR5443 conrods?

These conrods are designed for high-performance applications in the Nissan TB48 engine, suitable for both racing and modified street use. They provide a strong and lightweight option for builds aiming for increased power and reliability.

What is the weight of the SCR5443 conrods and how does it affect performance?

The total weight of each SCR5443 conrod is approximately 785 grams. A lighter conrod can improve engine response and reduce stress on the rotating assembly, but ensure that the entire rotating assembly is balanced for optimal performance.

Can I use these conrods with other Nissan engines?

The SCR5443 conrods are specifically designed for the TB48 engine. While they may physically fit in other Nissan engines, it is crucial to verify compatibility with the specific engine's dimensions and performance requirements.

What type of fasteners are included with the SCR5443 conrods?

The SCR5443 conrods come with 3/8 WMC ARP2000 bolts as standard. For optimal performance, follow the recommended torque specifications or stretch measurements as per ARP's guidelines.
