Performance Springs Ford BA/BF/FG XR Barra Turbo PACALOY™ Ovate Beehive Valve Springs

Upgrade the valve train of your Ford Barra-powered performance engine with Performance Springs PS BH103B104 PACALOY™ Ovate Beehive Valve Springs.

Designed specifically for the Ford BA/BF/FG XR inline 6-cylinder Turbo (Barra) engine, these custom PACALOY™ ovate beehive single valve springs are manufactured for Performance Valve Springs and provide increased valve train control for performance applications.

The PS BH103B104 valve springs are rated for up to 0.500" maximum valve lift, with a 105 lb seated pressure and 250 lb open pressure at 0.500" lift.

• 24 × Performance Springs
• 24 × Shims

Key Features

• PACALOY™ ovate beehive valve spring design

• Manufactured in the USA

• Direct drop-in fitment for Barra BA/BF engines

• Retains factory valve spring retainers and locks

• Improved fatigue resistance and valvetrain stability

• Single spring configuration for reduced mass

Spring Specifications

• Maximum Valve Lift: 0.500"

• Maximum Valve Lift: 0.500"

• Installed Height: 1.470"

• Seated Pressure: 105 lb

• Open Pressure: 250 lb @ 0.500"

• Retainers: Use STD

These springs are a purpose-built solution for the Ford BA/BF/FG XR Barra Turbo platform and are suitable for performance engine builds where improved valve train control is required.

Important: Valve spring pressure specifications have an approximate ±8% tolerance. Always verify spring dimensions, installed height, valve lift, pressures, coil bind clearance, retainer compatibility and application suitability before installation. The installer is responsible for checking all specifications before, during and after installation.

Engine Compatibility

• Ford BA/BF/FG XR Barra Turbo platform
