Raceworks 1.6L Black Slimline Catch Can ALY-155BK
Compact 1.6L baffled catch can with twin AN-12 breathers, two AN-12 ORB ports and an AN-10 drain tap.
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
The Raceworks ALY-155BK slimline catch can manages crankcase vapour in a narrow rectangular package. Its 1.6L nominal capacity provides 1.1L usable volume, with internal baffling and two external AN-12 breathers.
Specifications
| Capacity | 1.6L nominal; 1.1L usable |
|---|---|
| Connections | Two AN-12 ORB ports, twin AN-12 breathers and AN-10 drain with tap |
| Dimensions | 279mm high including breathers and drain; 203mm high excluding breathers and drain; 160mm body height; 130mm wide; 80mm deep |
Check space above and below the body for the breathers, drain and hose connections before ordering. Plumbing fittings may be required for your installation.
| Product Name | Raceworks 1.6L Black Slimline Catch Can ALY-155BK |
|---|---|
| Brands | Raceworks |
Delivery & Freight
We are an Australian-based company that ships items nationally and internationally, usually within 48 hours of receiving your order. High-value items shipped internationally are sent via DHL Express, while lower-value items are sent via Australia Post Express unless otherwise instructed.
You can calculate shipping rates inside the shopping cart. After adding all the products you would like, navigate to the cart and click the ESTIMATE SHIPPING & TAX link. .
If you only see the Click and Collect shipping option, it means that your address was not validated correctly.
If you have issues calculating freight, please get in touch. We are happy to help.
If you are outside of Australia, you are responsible for any duty or taxes charged by your government."
Disclaimer:
Product images are for description purposes only. Actual product may vary.
Shipping calculations available at checkout.
If you are unsure, get in touch by emailing [email protected], messaging us on Facebook, or phoning us at +61 7 5645 1333 (8am to 2pm AET).
What is the usable capacity?
The nominal capacity is 1.6L and usable volume is 1.1L.
How much clearance is required?
Allow for a total height of 279mm including the breathers and drain tap, plus room for hoses and servicing.
What ports does it use?
It has two AN-12 ORB ports, twin AN-12 breathers and an AN-10 drain with tap. Match the hose fittings to your installation.
-
-
