Performance Springs Ford BA BF FG XR Barra Inline 6 Turbo Single Beehive Valve Springs
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
Performance Springs PS BH103 Single Beehive Valve Springs are designed specifically for the Ford BA/BF/FG XR Inline 6-cylinder Turbo (Barra) engine.
These PACALOY™ Ovate Beehive Single Valve Springs are custom manufactured for Performance Valve Springs and are designed to provide improved valve train control for performance Ford Barra turbo applications.
The PS BH103 is suitable for applications with up to 0.520" maximum valve lift and uses standard retainers.
Product Specifications:
- Spring Type: Single Beehive
- Maximum Valve Lift: 0.520"
- Installed Height: 1.470"
- Seated Pressure: 95 lb
- Open Pressure: 235 lb @ 0.500" lift
- Retainers: Standard (STD)
What's Included:
- 24 × Performance Springs PS BH103 Single Beehive Valve Springs
Performance Valve Springs specifies that a Ford BA/BF/FG XR Inline 6-cylinder Turbo (Barra) requires 24 × PS BH103 springs. The supplier's ordering system automatically adds the correct quantity when the product is ordered.
Important: Always verify valve lift, installed height, spring dimensions, pressures, retainer compatibility and application suitability before installation. Performance Valve Springs states that valve spring pressure specifications have an approximate ±8% tolerance. The installer is responsible for checking and rechecking all dimensions, pressures, applications and specifications before, during and after installation.
| Product Name | Performance Springs Ford BA BF FG XR Barra Inline 6 Turbo Single Beehive Valve Springs |
|---|---|
| Brands | Performance Springs |
| Engine | Barra XR6 |
| Make | Ford, Mazda |
