Haltech Elite 750 ECU + Plug and Pin Set

The Elite 750 ECU utilizes the Nexus Software Programmer (NSP), providing an intuitive, user-friendly interface that makes it easier than ever to tune and manage engine performance. Whether you're tuning for naturally aspirated or forced induction applications, this ECU provides the flexibility and control needed to get the most out of your setup.

• Supports 1 to 12 Cylinder Engines – Ideal for a wide range of engine configurations.


• 1 to 3 Rotor Engines – Can handle rotary engine setups for unique applications.


• Fuel and Ignition Control – 6 x Fuel Injection Outputs (peak and hold, 0-8A peak / 0-2A hold), and 6 x Ignition Outputs for optimal control.


• Flexible Injection Patterns – Supports staged, sequential, semi-sequential, batch, or multipoint injection setups.


• Wide Range of Ignition Systems – Works with distributor ignition, multi-coil systems, expanded CDI range, or Haltech Multiplex CDI systems for maximum flexibility.


• Load Sensing – Can use Throttle Position (TPS), Manifold Absolute Pressure (MAP), or Mass Air Flow (MAF) sensors for precise load sensing.


• Onboard Data Logging – Stores crucial data for later analysis, helping you fine-tune performance.


• Waterproof Case (IP67) – Ensures durability and reliability in harsh conditions when the USB cover is fitted.


• Easy Connectivity – Connects to a wide range of display dashes and expansion devices via CAN for expanded functionality.


• Superseal Connector – Ensures a secure, reliable connection for critical wiring.

• 2 x Dedicated Engine Position Inputs – With extensive trigger type support for precise engine position monitoring.


• 2 x Digital Pulsed Inputs – For additional signal inputs such as cam sensors or other data sources.


• 5 x Digital Pulsed Outputs – For controlling external devices like relays, solenoids, or additional sensors.


• 2 x Analogue Voltage Inputs – For monitoring sensors like air-fuel ratio or other critical variables.


• 3 x Dedicated Inputs – For critical sensors such as Throttle Position, Coolant Temperature, and Air Temperature.


• Internal 3Bar MAP Sensor – Rated up to 200kPa of boost (2Bar/29psi), ideal for forced induction systems.


• Up to 45 Channels of I/O Expansion via CAN – For seamless integration with other devices and systems.

• USB Laptop Communication (Windows) – Use Haltech's NSP Calibration Software, an intuitive and easy-to-use tool for configuring and fine-tuning your ECU setup.


• 34 Position AMP Connector – A reliable connection interface for easy wiring and installation.
