Performance Springs Toyota 7MGTE Valve Spring Set
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
Valve Spring Set for Toyota 7MGTE Engines
This spring set is designed for 7MGTE engines operating under elevated boost or upgraded camshaft profiles. The spring geometry provides increased load across the operating stroke while maintaining predictable force progression.
Spring Characteristics
- O.D.: 0.930"
- I.D.: 0.665"
- Installed: 50 lbs at 34.1 mm
- Open: 135 lbs at 24.1 mm
- Coil Bind: 0.875"
| Product Name | Performance Springs Toyota 7MGTE Valve Spring Set |
|---|---|
| Brands | Performance Springs |
| Engine | 7MGTE |
| Make | Toyota |
Delivery & Freight
We are an Australian-based company that ships items nationally and internationally, usually within 48 hours of receiving your order. High-value items shipped internationally are sent via DHL Express, while lower-value items are sent via Australia Post Express unless otherwise instructed.
You can calculate shipping rates inside the shopping cart. After adding all the products you would like, navigate to the cart and click the ESTIMATE SHIPPING & TAX link. .
If you only see the Click and Collect shipping option, it means that your address was not validated correctly.
If you have issues calculating freight, please get in touch. We are happy to help.
Disclaimer:
Product images are for description purposes only. Actual product may vary.
Shipping calculations available at checkout.
If you are unsure, get in touch by emailing [email protected], messaging us on Facebook, or phoning us at +61 7 5645 1333 (8am to 2pm AET).
What information do I need to match these pistons to my engine?
You need the engine code, bore size, stroke, rod length, pin diameter and target compression ratio. These determine the correct piston compression height and crown design.
How should ring gaps be set for these pistons?
Ring gaps must be set by your engine builder based on fuel type, boost level and the intended rpm range. Forced-induction engines usually require larger gaps.
Are forged pistons suitable for street engines?
Yes. Forged pistons handle detonation and high cylinder pressure better than cast units. Your builder should set the piston-to-bore clearance to suit your application.
What are the specifications of the Performance Springs for the Toyota 7MGTE?
The Performance Valve Springs for the Toyota 7MGTE have an outer diameter of 0.930 inches, an inner diameter of 0.665 inches, and a spring rate of 50 lbs at a height of 1.345 inches (34.1mm) and 135 lbs at 0.950 inches (24.1mm). The coil bind height is 0.875 inches.
Are these valve springs suitable for high-performance applications?
Yes, these valve springs are designed for high-performance applications in the Toyota 7MGTE engine. They can handle increased RPM and higher lift cam profiles, making them suitable for modified engines that require enhanced valve control.
Do I need to modify my cylinder head to fit these valve springs?
In most cases, these valve springs should fit the stock 7MGTE cylinder head without modification. However, it is advisable to check for coil bind clearance and ensure that the installed height is within specifications to avoid any interference.
What should I consider when installing these valve springs?
When installing these valve springs, ensure that the spring seats are clean and free of debris. It's also important to check the installed height and ensure it matches the specifications to maintain proper spring tension and performance.
Can I use these valve springs with aftermarket camshafts?
Yes, these valve springs are compatible with aftermarket camshafts designed for the 7MGTE engine. However, it's crucial to verify that the camshaft lift does not exceed the spring's coil bind height of 0.875 inches to prevent damage.
