Performance Springs Toyota 1VD-FTV 32V V8 Single Valve Springs – PS 3302
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
Performance Springs PS 3302 Single Valve Springs are designed specifically for the Toyota 1VD-FTV 32V V8 engine.
These performance valve springs are designed to provide improved valve train control for Toyota 1VD-FTV applications, with a maximum valve lift specification of 0.390".
The PS 3302 installs at 1.230" installed height, providing 55 lb of seated pressure and 110 lb of open pressure at 8.35 mm lift.
The springs feature a 22.33 mm outside diameter, 16.1 mm inside diameter and 19.7 mm coil bind height. The supplier specifies the use of standard (STD) retainers.
A complete Toyota 1VD-FTV 32V V8 requires 32 × PS 3302 valve springs.
Spring Specifications
- Engine: 1VD-FTV
- Configuration: 32V V8
- Spring Type: Single Valve Spring
- Maximum Valve Lift: 0.390"
- Retainers: Standard (STD)
- Installed Height: 1.230"
- Seated Pressure: 55 lb
- Open Pressure: 110 lb @ 8.35 mm lift
- Outside Diameter: 22.33 mm
- Inside Diameter: 16.1 mm
- Coil Bind: 19.7 mm
Application
- Toyota 1VD-FTV 32V V8
What's Included
- 32 × Performance Springs PS 3302 Single Valve Springs
The supplier specifies that a Toyota 1VD-FTV 32V V8 requires 32 PS 3302 springs. When ordering a complete engine set, the required quantity is 32 springs.
Installation Information
Always verify installed height, valve lift, spring pressure, coil bind clearance, retainer compatibility and all other dimensions against the specific engine and cylinder head configuration before installation.
Performance Valve Springs recommends that all dimensions, pressures, applications and specifications are checked and rechecked before, during and after installation.
| Product Name | Performance Springs Toyota 1VD-FTV 32V V8 Single Valve Springs – PS 3302 |
|---|---|
| Brands | Performance Springs |
| Engine | 1VD-FTV |
| Make | Toyota |
Delivery & Freight
We are an Australian-based company that ships items nationally and internationally, usually within 48 hours of receiving your order. High-value items shipped internationally are sent via DHL Express, while lower-value items are sent via Australia Post Express unless otherwise instructed.
You can calculate shipping rates inside the shopping cart. After adding all the products you would like, navigate to the cart and click the ESTIMATE SHIPPING & TAX link. .
If you only see the Click and Collect shipping option, it means that your address was not validated correctly.
If you have issues calculating freight, please get in touch. We are happy to help.
If you are outside of Australia, you are responsible for any duty or taxes charged by your government."
Disclaimer:
Product images are for description purposes only. Actual product may vary.
Shipping calculations available at checkout.
If you are unsure, get in touch by emailing [email protected], messaging us on Facebook, or phoning us at +61 7 5645 1333 (8am to 2pm AET).
Which engine do PS 3302 valve springs suit?
They are designed for the Toyota 1VD-FTV 32-valve V8 engine. The cylinder-head and valvetrain dimensions should still be verified before installation.
How many PS 3302 valve springs are included?
This listing supplies 32 single valve springs, enough for one complete Toyota 1VD-FTV 32-valve engine.
What are the spring pressure specifications?
At the specified 1.230-inch installed height, seated pressure is 55lb and open pressure is 110lb at 8.35mm lift. Maximum specified valve lift is 0.390 inch.
Can the original retainers be used?
The supplier specifies standard retainers for this spring, but the installer must confirm retainer, lock and spring compatibility with the specific cylinder-head components.
What must be checked during installation?
Verify installed height, actual spring pressure, valve lift, coil-bind clearance, retainer compatibility, seal clearance and all other valvetrain dimensions before final assembly.
