Forged Pistons for Nissan SR20VE/VET 87 12.5:1 (CP Pistons SC7342V)

Name: Forged Pistons for Nissan SR20VE/VET 87 12.5:1 (CP Pistons SC7342V)
Brand: CP Carrillo
SKU: SC7342V
Price: 1431 AUD
Availability: InStock

Please allow up to 10 days for dispatch. Please fee free to contact us before purchase to get a confirmed shipping date.

Be the first to review this product

AUD$1,300.91

SKU

SC7342V

Piston Pin Upgrades

Quantity:

+ -

Add to Compare

Add to Wish List Share

Copy Link

For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.

Details

More Information

DELIVERY & FREIGHT

DISCLAIMER

Faq

Make	Nissan
Model	SR20VE/VET
Part Number	SC7342V
Cylinders	4
Bore (in)	3.425
Bore (mm)	87
Size	+1.0mm
Stroke	86
Conrod	136.25
Comp Height (in)	1.26
Comp Height (mm)	32
Dom/Dish CC	5.4
Compression Ratio	12.5
Weight (Grams)	328
Pin (mm)	22
Rings	CPN-3425
Ring Thickness	1.0 x 1.2 x 2.8mm
Pin included (Standard)	866-2250-15CP1C
Upgraded Pin	866-2250-20CP3C
Ultra Duty Pin	866-2250-25CP3C
Locks	866x063 SWL

CP pistons are compatible with oversized valves and high lift camshafts. CP Pistons represent the highest quality and is engineered for maximum power. Standard features include: Deep valve reliefs accommodate high lift camshafts; Larger valve reliefs for +1mm valve sizes; Custom skirt cam and barrel design; Accumulator grooves; High strength aluminum forgings; High performance rings; Fully CNC machined and balanced to +/- 1 gram; Wrist pins included at no additional cost; Double pin oilers force fed from oil ring groove; Pin lock grooves for easy lock removal; Pin fitting included.

More Information
Product Name	Forged Pistons for Nissan SR20VE/VET 87 12.5:1 (CP Pistons SC7342V)
Brands	CP Carrillo
Engine	SR20
Make	Nissan

Delivery & Freight

We are an Australian-based company that ships items nationally and internationally, usually within 48 hours of receiving your order. High-value items shipped internationally are sent via DHL Express, while lower-value items are sent via Australia Post Express unless otherwise instructed.

You can calculate shipping rates inside the shopping cart. After adding all the products you would like, navigate to the cart and click the ESTIMATE SHIPPING & TAX link. .

If you only see the Click and Collect shipping option, it means that your address was not validated correctly.

If you have issues calculating freight, please get in touch. We are happy to help.

Disclaimer:

Product images are for description purposes only. Actual product may vary.

Shipping calculations available at checkout.

If you are unsure, get in touch by emailing sales@spoolimports.com, messaging us on Facebook, or phoning us at +61 7 5645 1333 (8am to 2pm AET).

What material are CP-Carrillo forged pistons made from?

CP-Carrillo pistons are manufactured from high-strength 2618-T61 aluminium alloy forgings. This alloy offers excellent durability under high heat and high cylinder pressures, making it ideal for boosted and high-performance sport compact engines.

What is included with a CP-Carrillo piston kit?

Each CP-Carrillo piston kit includes forged pistons, high-quality piston rings, wrist pins (gudgeon pins), and locks. Everything you need for the piston assembly is included in the box.

Can the wrist pins be upgraded?

Yes. CP-Carrillo wrist pins can be upgraded to stronger 9310 steel pins. These upgraded pins provide increased resistance to bending and fatigue under extreme loads.

Why would I upgrade to 9310 wrist pins?

Upgrading to 9310 pins is recommended for high-boost, high-RPM, or nitrous applications. The stronger 9310 material provides additional support for the piston and reduces the risk of pin flex or failure when cylinder pressures are significantly above factory levels.

Do CP-Carrillo pistons come with performance ring sets?

Yes. Every CP-Carrillo piston kit includes a performance ring pack matched to the piston design. This ensures maximum sealing and reliability in high-load environments.

Do CP-Carrillo pistons require special fitment or machining?

Yes. As with any forged performance piston, correct piston-to-wall clearance, ring end gaps, deck height, and pin fitment must be verified during assembly. Proper machining ensures maximum performance and longevity.

Do you have these pistons in stock?

We keep a large range of popular CP-Carrillo pistons in stock. If a particular set isn’t on our shelves, we receive weekly DHL Express shipments direct from CP-Carrillo. Orders for out-of-stock items usually ship the following week — CP dispatches on Friday (USA time) and we receive the shipment on Tuesday or Wednesday afternoon.

Some piston part numbers are made to order, and CP-Carrillo may or may not have these available immediately. Even regularly stocked items can occasionally be temporarily out of stock. We have live inventory visibility with CP-Carrillo and can check availability for you at any time.

If a piston set is not currently available at CP-Carrillo, the typical lead time is 3–5 weeks.
