Forged Pistons for Ford, 2.0L Eco Boost, 87.5mm, 10:1 For use with 22mm pin aftermarket rods (CP Pistons SC7528)
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
|
Make |
Ford |
|
Model |
2.0L Eco Boost |
|
Part Number |
SC7528 |
|
Cylinders |
4 |
|
Bore (in) |
3.445 |
|
Bore (mm) |
87.5 |
|
Size |
STD |
|
Stroke |
87.5 |
|
Conrod |
155.8 |
|
Comp Height (in) |
1.289 |
|
Comp Height (mm) |
32.7 |
|
Dom/Dish CC |
|
|
Compression Ratio |
10 |
|
Weight (Grams) |
363 |
|
Pin (mm) |
22 |
|
Rings |
CPN-3445 |
|
Ring Thickness |
1.0 x 1.2 x 2.8mm |
|
Pin included (Standard) |
866-2250-18CP3C |
|
Upgraded Pin |
NA |
|
Ultra Duty Pin |
866-2250-25CP3C |
|
Locks |
866x063 SWL |
CP pistons are compatible with oversized valves and high lift camshafts. CP Pistons represent the highest quality and is engineered for maximum power. Standard features include: Deep valve reliefs accommodate high lift camshafts; Larger valve reliefs for +1mm valve sizes; Custom skirt cam and barrel design; Accumulator grooves; High strength aluminum forgings; High performance rings; Fully CNC machined and balanced to +/- 1 gram; Wrist pins included at no additional cost; Double pin oilers force fed from oil ring groove; Pin lock grooves for easy lock removal; Pin fitting included.
| Product Name | Forged Pistons for Ford, 2.0L Eco Boost, 87.5mm, 10:1 For use with 22mm pin aftermarket rods (CP Pistons SC7528) |
|---|---|
| Brands | CP Carrillo |
| Engine | 2.0L Eco Boost |
| Make | Ford |
