CP Pistons EJ255 WRX
For shipping cost -add all the products you would like, then navigate to the shopping cart to calculate shipping quote.
CP Pistons for EJ255 WRX Engines
Enhance the performance of your Subaru WRX with the high-quality CP Pistons designed specifically for EJ255 engines. These pistons are engineered to deliver superior strength and reliability, ensuring your engine runs smoothly under high-stress conditions. Perfect for both street and track applications, CP Pistons are a trusted choice for automotive enthusiasts seeking to maximize their vehicle's potential.
Key Features:
- Bore Size: 100mm (+0.5mm) for optimal fit and performance
- Compression Ratio: 8.4:1, providing a balanced blend of power and efficiency
- Part Number: SC7431, ensuring compatibility with EJ255 WRX engines
- Constructed from high-strength materials for durability and longevity
- Precision-engineered for enhanced performance and reliability
- Ideal for both street and competitive racing environments
Detailed Specifications:
|
Make |
Subaru |
|
Model |
EJ255 WRX |
|
Part Number |
SC7431 |
|
Cylinders |
4 |
|
Bore (in) |
3.937 |
|
Bore (mm) |
100 |
|
Size |
+0.5mm |
|
Stroke |
79 |
|
Conrod |
130.5 |
|
Comp Height (in) |
1.208 |
|
Comp Height (mm) |
30.7 |
|
Dom/Dish CC |
-24.3 |
|
Compression Ratio |
8.4 |
|
Weight (Grams) |
396 |
|
Pin (mm) |
23 |
|
Rings |
RS1658-3937-0 |
|
Ring Thickness |
1.2 x 1.2 x 2.0mm |
|
Pin included (Standard) |
905-2500-18CP1S |
|
Upgraded Pin |
905-2500-20CP3S |
|
Ultra Duty Pin |
905-2500-26CP3S |
|
Locks |
905x055 SUB |
CP pistons are compatible with oversized valves and high lift camshafts. CP Pistons represent the highest quality and is engineered for maximum power. Standard features include: Deep valve reliefs accommodate high lift camshafts; Larger valve reliefs for +1mm valve sizes; Custom skirt cam and barrel design; Accumulator grooves; High strength aluminum forgings; High performance rings; Fully CNC machined and balanced to +/- 1 gram; Wrist pins included at no additional cost; Double pin oilers force fed from oil ring groove; Pin lock grooves for easy lock removal; Pin fitting included.
| Product Name | CP Pistons EJ255 WRX |
|---|---|
| Brands | CP Carrillo |
| Engine | EJ255 WRX |
| Make | Subaru |
