Holden / GM LS1,LS2 LS3 - 4.00

Holden / GM LS1,LS2 LS3 - 4.00" OEM Stroke Rebuild Kit

Rebuild kit for Nissan VG30DET

Availability: In stock

This Rebuild Kit includes the following quality parts:

  • Carrillo Conrods
  • CP Forged Pistons (Rings, Pins and Locks Included)
  • 2x Cometic MLS Head Gasket
  • ACL Race Series Main Bearings - STD or 0.25mm
  • ACL Race Series Big End Bearings - STD or 0.25mm

Pistons are available in:

  • Bore: 87.5mm (+.5mm) / Comp: 8.5:1 - Part#: SC7335
  • Bore: 88mm (+1mm) / Comp: 8.5:1 - Part#: SC7336
  • Pistons come with rings, gudgeon pins and pin locks

CP Pistons standard features include:

  • 5310 gudgeon pins (9310 thicker wall thickness pins are available as an upgrade)
  • Deep valve reliefs accommodate high lift camshafts
  • Larger valve reliefs for +1mm valve sizes
  • Custom skirt cam and barrel design
  • Accumulator grooves
  • High strength aluminium forgings
  • High performance rings
  • Fully CNC machined and balanced to +/- 1 gram
  • Wrist pins included
  • Double pin oilers force fed from oil ring groove
  • Pick lock grooves for easy lock removal
  • Pin fitting included

Four difference conrods are available:

  • SCR5446 Carrillo Conrods for 6 cyl Nissan VG30 Pro-A 3/8 Bolt (NI-VG3-1>A-66070H ) - Made to Order (13 weeks)
  • SCR4890 Carrillo Conrods for 6 cyl Nissan VG30 / VG33 Super-A Bolt (NI-VG3>SA-66070H ) - Made to Order (13 weeks)
  • SCR4878 Carrillo Conrods for 6 cyl Nissan VG30 Pro-H 3/8 Bolt (NI-VG3>-66070H ) - Made to Order (13 weeks)
  • SCR4880 Carrillo Conrods for 6 cyl Nissan VG30 Pro-H 3/8 CAR Bolt (NI-VG3>-66070S ) - Regular Stock (normally 2 weeks)

Spool Connecting Rods Feature:

    CP-Carrillo uses a proprietary steel to manufacture its connecting rods, named Carrilloy. It is a chrome, nickel, moly, vanadium alloy which meets all VAR (vacuum arc re-melt ASTM standards). Carrilloy is simply a modification of an existing SAE specification. We just tighten up the acceptable attributes of the heat as it is manufactured. The heat is validated, both by the supplier and an independent metallurgist whom confirm the desired physical and chemical properties of steel.

Note: We recommend Joe Gibbs Break in Oil for all new engines.

More Information
Product Name Rebuild kit for Nissan VG30DET
Engine VG30
Make Nissan
